Graphical User Interface
73
Options
ASCII pane
Display checksum
Limit dump to sub-layer
size
Signed decimal and hex
values
Always display '+' or '-'
Leading zeroes for decimal
numbers
Reverse bytes in words
( LSB first)
Reverse words in dwords
Reverse dwords in qwords
Non-printable ASCII
characters
Replace characters
0х00...0х20
Replace characters
0х80...0хFF
The options here customize the display format.
If the box is checked the right pane will display ASCII characters
corresponding to the data in the buffer dump.
If the box is checked the calculated checksum will be displayed in
the blue strip over the data dump, right under the window local
toolbar.
If the box is checked the window dump will display a part of memory
equal to the active sub-layer's size.
If the box is checked the most significant bit (MSB) in the data
shown in the binary or hexadecimal formats will be treated as a
sign. If MSB=1 the data is negative, if MSB=0 they are positive.
This is a sub-setting for the Signed decimal and hex values option. If
both boxes are checked then the signs '+' and '-' will be displayed.
If the box is checked then each decimal data will be shown with a
number of zeros before the first significant digit - for example the
value of 256 will be presented as 00000256.
If the box is checked then the order of bytes in words will be
reversed, e.g. the MSB will follow the LSB.
If the box is checked then the order of 16-bit words in 32-bit words
will be reversed.
If the box is checked then the order of 32-bit words in 64-bit words
will be reversed.
The characters from the ranges 0х00...0х20 and 0х80...0хFF are non-
printable. The options here customize presentations of non-printable
ASCII characters in the ASCII pane of the buffer dump window.
If the box is checked then all the characters belonging to the range
0х00...0х20 will be replaced with the character dot ('.') or space (' '). The
pair of toggling radio buttons Replace with: sets the replacement
character - dot ('.') or space (' ').
If the box is checked then all the characters belonging to the range
0х80...0хFF will be replaced with the character dot ('.') or space (' '). The
pair of toggling radio buttons Replace with: sets the replacement
character - dot ('.') or space (' ').
? 2010 Phyton, Inc. Microsystems and Development Tools
